Equus D2860

This 2U 28-bay dual Intel® 2nd Gen Xeon® Scalable stream server platform features:

  • Dual Intel® 2nd Gen Xeon® Scalable processor support (LGA-3647 socket) up to 205W TDP
  • 28x 3.5″ hot-swap HDD drive bays
  • 16x DDR4 ECC DIMM Memory Slots
  • Onboard 1x PCIE 4th Gen NVMe M.2 slots
  • Dual 1GbE RJ45 (Intel I210-AT) network ports + a 1GbE RJ45 iKVM port
  • Onboard graphics (VGA port)
  • Onboard USB 3.0 (2x Rear)
  • Power Supply: 1+1 Redundant 850W 80 Plus Platinum Power Supplies

[Datasheet]

Pricing available upon request

Base Configuration includes:
Processors: Dual Intel Xeon Gold 5220 (2.2GHz 18C/36T 24.75MB 125W)
Memory: 384GB SDRAM (12X 32GB DDR4-3200 ECC RDIMMs)
Storage: 224TB Total Capacity (28x 8TB 3.5" SATA HDD) with dual LSI 9305-16I HBAs
Operating System: --- NOT INCLUDED ---
Warranty: Equus Standard US Depot (3-year)

  • Processors *

  • Memory *

  • Storage *

  • Internal 2.5" Drive Options *

  • Networking Add-on Options *

  • Operating System *

  • Warranty Option *

Product total

Options total

Grand total
